Dynamic vibration analysis of ballastless track: Istanbul Aksaray-Airport LRT System

Veysel Arlı, Turgut Öztürk, Zübeyde Öztürk


DOI: https://doi.org/10.20528/cjsmec.2015.07.026
View Counter: Abstract | 1482 times | ‒ Full Article | 354 times |

Full Text:

PDF

Abstract


In this study, ballastless superstructure with a steel base-plate of light metro track, which lies between Aksaray and the Airport in Istanbul, was analyzed with a numeric method using ANSYS 9.0 finite element software. Since the railroad superstructure has a symmetric structure with respect to the track axis, a rail system that consists of a single rail and a half sleeper was modeled to simplify the computations in this analysis. In the discrete supported track model, the rail was modeled as an Euler-Bernoulli beam and steel base-plate, and it was assumed to be a rigid mass. Dynamic computation results and graphs were determined by performing harmonic analysis with the aid of ANSYS software. A field vibration survey was conducted to determine the natural frequencies of the railroad and the dynamic receptance behavior, and to validate the finite element model according to the measurement results. The frequency receptance behavior of the rail and the support was measured by applying a hammer impact load on the rail head in the field, and the finite element model of the ballastless track with steel base-plate was verified.


Keywords


finite element method; numeric analysis; dynamic analysis; ballastless track; vibration analysis

References


Arlı V (2009). Demiryolu Titreşimlerinin Model Hat Üzerinde Çok Yönlü Analizi. Ph.D. thesis, İstanbul Technical University, İstanbul, Turkey (in Turkish).

Dahlberg T (2002). Dynamic interaction between train and non-linear track model. Proceedings of the 4th International Conference on Structural Dynamics, EURODYN2002, Munich.

Diana G, Cheli F, Bruni S, Collina A (1994). Interaction between railroad superstructure and track vehicles. Vehicle System Dynamics, 23, 75-86.

http://dx.doi.org/10.1080/00423119308969506

Grassie SL, Kalousek J (1993). Rail corrugation: characteristics, causes and treatments. Proceedings of the Institution of Mechanical Engineers, Part F, Journal of Rail and Rapid Transit, 207(F1), 57-68.

http://dx.doi.org/10.1243/PIME_PROC_1993_207_227_02

Grassie SL (1996). Models of track and train-track interaction at high frequencies: Results of benchmark test. Vehicle System Dynamics, 25, 243-262.

http://dx.doi.org/10.1080/00423119608969199

Knothe KL, Grassie SL (1993). Modelling of track and vehicle-track interaction at high frequencies. Vehicle System Dynamics, 22, 209-262.

http://dx.doi.org/10.1080/00423119308969027

Nielsen JCO (1993). Train Track Interaction: Coupling of Moving and Stationary Systems - Theoretical and Experimental Analysis of Track Structures Considering Wheel and Track Imperfections. Ph.D. thesis, Division of Solid Mechanics, Chalmers University of Technology, Gothenburg, Sweden.

Popp K, Schiehlen W (2003). System Dynamics and Long-Term Behavior of Track Vehicles, Track and Subgrade, Berlin.

http://dx.doi.org/10.1007/978-3-540-45476-2

Sato Y, Odaka T, Takai H (1988). Theoretical analyses on vibration of ballasted track. Quarterly Reports of Track Technical Reassuring Institute (Japan), 29(1), 30-32.
